Falcon S Full-Suspension eMTB

Falcon S Full-Suspension eMTB

18 in stock

BCBA1BL

Color
Size

Introducing the Falcon S, designed for dealers seeking to offer customers an all-terrain powerhouse with minimal effort required. Its soft-tail structure ensures a more comfortable ride, enhanced traction, and improved control for diverse off-road adventures. The ROCKSHOX four-bar suspension system delivers superior shock absorption, while the BAFANG Mid-Drive motor, with up to 1000W of power and 160 Nm of torque, provides exceptional performance on challenging terrain. The Falcon S is equipped with 29x3" MTB fat tires, ensuring effortless handling across various road conditions, making it a perfect choice for customers looking for power and versatility.

Check out here for more info.

User Manual

Download Falcon S Owner's Manual

View full details

Falcon S eMTB - Test & Review

Specifications

E-bike System
Battery 48V/20Ah, 960Wh Lithium-ion battery with LG 21700 cells
Motor BAFANG Mid-drive, 1000W rated power, 1100W peak power, 160 Nm of torque, based on CAN6.3 protocol
Range 65 miles
Display LCD display with Bluetooth, 4" TFT color screen, IP66
Charger 54V 3A
Charging Time Approx. 6-8 hours
Sensor Torque sensor
Max Speed 28MPH
Pedal Assist Modes 5
Frameset
Frame Aluminum alloy, 150mm travel
Fork ROCKSHOX FS RCNS RL, 150mm travel, pneumatic bumper, hydraulic lockout
Shock ROCKSHOX RS-DELUXE SELECT-C1, 190mmx45mm, iDebonAir+ air spring, Maxima Plush dynamic suspension lubricant
Wheels
Rim Aluminum ring, 12G 36H AV
Front Tire Maxxis Minion DHF, 29x3.0"
Rear Tire Maxxis Minion DHR II, 29x3.0"
Front Hub Aluminum alloy, disc brake, 12G 36H, ID15*110mm
Rear Hub Aluminum alloy, disc brake, 12G 36H, ID12*148mm
Spoke Black stainless, 12G
Drivetrain
Shifter SRAM RD X5 9S, 9 speed
Crank arm BAFANG 170mm length
Chainring BAFANG MM G510, 40T
Chain KMC E10S for e-bikes
Components
Saddle VELO, boron steel, 160mm width
Grips VELO, trail grip
Brakes TEKTRO HD-E730, 4-piston caliper, hydraulic disc, with power cut-off sensor
Brake rotor TEKTRO HD-E730, 3T, 203x2mm
Weight
Weight Limit 300 lbs
Net Weight 66 lbs
Gross Weight 100.3 lbs
Box Dimension 68.7 x 34.1 x 11 in
